Χαρακτηριστικά
- Capacity 24000BTU
- Rated volt and frequency V/Hz 220-240V~/50HZ
Cooling
- Rated capacity W 6840(1830~7820)
- Power input W 2099
- Current input A 9,80
- SEER-SCOP/ Energy Class W/W 6,5 A++
- Operating range (°C) 0 – 53°C
- Energy consumption (per year, based on standard test results) kwh 390
Heating
- Rated capacity W 7050(1850~7960)
- Power input W 1900
- Current input A 8,60
- SEER-SCOP/ Energy Class W/W 4 A+++
- Operating range (°C) -20°C – 30°C
- Energy consumption (per year, based on standard test results) kwh 1680
- Dehumidifying Kg/h 2,0
- Degree of protection (IN) / (OUT) (IP) IPX4/IPX4
- Class of electric protection (IN) / (OUT) Class I / Class II I/I
- Max. input consumption W 3000
- Max. current A 14,00
Compressor
- Model KSN98D32UEZ
- Type Rotary
- Brand SANYO
Indoor Fan motor
- Indoor fan Dia. / Length mm φ92×578
- Indoor Air Circulation m3/h 1100
- Indoor Noise Level dB dB(A) 52/48/44/40
- Net Dimension (L×W×H) mm 1100×333×222
- Packing Dimension (L×W×H) mm 1165×405×295
- Net Weight/Gross Weight Kg 14/17
Outdoor Fan motor
- Model 1170040162AB
- Power input W 33W output
- Capacity uF /
- Outdoor Fan Speed RPM r/min ≤1000
- Outdoor fan Length mm φ384×134
- Outdoor Noise Level dB dB(A) 57
- Net Dimension (L×W×H) mm 920×699×380
- Packing Dimension (L×W×H) mm 960×732×400
- Net Weight/Gross Weight Kg 40/43
- Refrigerant type/weight g R32/1.1kg
- Max. Discharge/Max. Suction pressure Mpa 3.7/1.2
Refrigerant piping
- Liquid side / Gas side mm 6.35/12
- Max. refrigerant pipe length / Max. difference in level m 25/10
